Description
| Parameter | Specification |
|---|---|
| System Type | Frameless Spider Glazing System |
| Glass Type | Toughened / Laminated / Double Glazed Glass |
| Glass Thickness | 10 mm – 19 mm (single), 24 mm – 32 mm (laminated/DGU) |
| Glass Configuration | 12 mm Toughened / 6+6 Laminated (common) |
| Fitting Material | Stainless Steel (SS 304 / SS 316) |
| Spider Types | 1-arm, 2-arm, 3-arm, 4-arm fittings |
| Bolt Type | High-strength SS Routel Bolts |
| Support Structure | MS Steel / Stainless Steel / Glass Fins / Cable Rod System |
| Sealant Type | Structural Silicone & Weather Silicone |
| Joint Gap | 10 mm – 20 mm (filled with silicone) |
| Surface Finish (Fittings) | Mirror / Satin Finish |
| Wind Load Resistance | Up to ±2.5 kPa (depending on design) |
| Water Tightness | Moderate (silicone sealed joints) |
| Thermal Insulation | Moderate (higher with DGU) |
| Sound Insulation | Moderate |
| Panel Size | Customizable (based on design & structural support) |
| Installation Method | On-site installation with precise alignment |
| Maintenance | Moderate (regular glass cleaning required) |
| Application Areas | Showrooms, malls, atriums, entrances, glass façades |
Spider Glazing System is a modern frameless glass façade solution that uses specially designed stainless steel spider fittings to hold glass panels together without conventional aluminium frames. This system creates a fully transparent, sleek, and high-end architectural appearance, widely used in commercial buildings and showrooms.
The glass panels are connected at fixing points using spider brackets and supported by steel structures, fins, or tension rods, ensuring both structural stability and aesthetic appeal.
