Description
| Parameter | Specification |
|---|---|
| System Type | Semi-Unitized Curtain Wall System |
| Frame Material | Aluminium Extrusions |
| Aluminium Alloy | AA6063-T5 / AA6063-T6 |
| Section Thickness | 1.4 mm – 2.5 mm |
| Surface Finish | Anodized / Powder Coated / PVDF Coating |
| Glass Type | Toughened / Laminated / Double Glazed Unit (DGU) |
| Glass Thickness | 6 mm – 12 mm (single), 18 mm – 28 mm (DGU) |
| Fixing System | Mullion-transom grid with pressure plate system |
| Sealant Type | Structural & Weather Silicone |
| Gasket Material | EPDM / Neoprene |
| Thermal Insulation | Moderate to High |
| Sound Insulation | Moderate to High |
| Air Infiltration | ≤ 2.0 m³/hr/m² |
| Water Tightness | Up to 450–600 Pa |
| Wind Load Resistance | Up to ±2.0 kPa (depending on design) |
| Panel Size | Flexible (customizable as per grid design) |
| Installation Method | Combination of site assembly & partial factory fabrication |
| Maintenance | Moderate |
| Application Areas | Commercial buildings, offices, malls, mid-rise structures |
Semi-Unitized Glazing System is a hybrid façade solution that combines the advantages of both stick glazing and unitized glazing systems. In this system, the main aluminium framing members (vertical mullions) are installed on-site, while certain components such as glass panels or sub-assemblies are pre-fabricated in factory conditions.
This approach offers a balance between cost-effectiveness and performance, making it suitable for mid-rise and commercial buildings where full unitized systems may not be required.
